ULTRA -S
| Model No. | LSHM-1500 ULTRA-S | LSHM-1800 ULTRA-S | |
| Wattage | 1500W | 1800W | |
| Power Supply | Inventronics
(optional MOSO S6) |
Powerland 0-10v DALI DM
(optional MOSO S6 DALI DMX) |
|
| Input Voltage | 100_300vAC | 100-300vAC | |
| Control | 0-10v 0-10v | ||
| Power Factor | >0.95 | ||
| Lifespan | 100000 hrs | ||
| SPD | 10KV/20KV optional | ||
| Color Temp | 3000k ~ 6000k | ||
| Operating Temperature | -40 ~ +55C | ||
| IP Rating | IP66 | ||
UNDER WATER LIGHT
| Model | UNDER WATER LIGHT | |
| Dimension(mm) | 170*95 | 120*95 | |
| Operating Voltage | DC 24V | |
| Wattage | 12W | 18W | |
| No. of LEDs | 12 NOS | 18 NOS | |
| LED Make | OSRAM | BRIDGELUX | |
| LED Colour | RGBW & Mono color | |
| Beam Angle | 11 | 15 | 30 | 60 | |
| Material | Stainless steel 304 | |
| Controlled Method | DMX512 | |
| Protection Rating | IP68 | |
| Operating Temp. | -10C – +50C | |
| Weight | 1550 g | 2300 g | |
| CUTOUT DIA | 160 | 195 | |
WALL WASHER DOUBLE ARRAY
The Wall Washer Double Array Series is a high-performance architectural LED lighting solution designed to provide powerful and uniform illumination for large indoor and outdoor spaces. Engineered with advanced LED technology and a durable housing structure, it delivers enhanced brightness, excellent energy efficiency, and long-lasting performance. Its double array design ensures wider light coverage and smooth light distribution, making it ideal for illuminating building facades, landscapes, bridges, monuments, and decorative architectural features. Built with reliable weather-resistant protection, the Wall Washer Double Array Series performs efficiently in diverse environmental conditions while creating stunning visual effects, making it a dependable choice for modern architectural and decorative lighting applications.
WS FLOOD LIGHTS
Model : LS9G-1000
Wattage : 1000W
Dimension : L520 ×W540 ×H604 mm
Weight : 30.80 Kgs
| Technical Parameters | |
| LED Colour | 3000K | 4000K | 6000K |
| Beam Angle | 9° | 15° | 30° | 45°| 60° |90° |
| Optical Cover | Polycarbonate LENS |
| Light Source | CREE | OSRAM | Bridge LUX |
| Housing | Aluminium Pressure Die-Casting |
| Power | AC 120 ~300V, 50 ~ 60HZ |
| Protection Rating | IP 66 |
| Lumen / W | 135|m / W |
| CRI | ≥70 Ra | ≥80 Ra |
| Operating Temperature | -10°C-+50°C |
| Driver | Integrated Driver |
| Power Factor & THD | >0.9 | <10% |
ZETA CHARGER
Zeta Charger for 3 Wheeler – New Electric Auto Rickshaw Charger in India with Wide input range, Charge Voltage cut-off, and Battery Reverse Protection
Specifications |
||||
|---|---|---|---|---|
| Input | 150VAC to 280VAC, 50Hz | |||
| Output | 58.4VDC @ 20A/ 25A/ 35A | |||
| PF | >0.98 | |||
| THD | <10% | |||
| Efficiency | >90% | |||
| Surge | 6kV (CM & DM) as per IEC 61000-4-5 | |||
Features |
||||
|---|---|---|---|---|
|
|
|||
